Special Price for Tvs Scan During Periods - Portable Sunbright 12.1 Inch Multiparameter Patient Monitor Module SUN-603M – Sunbright Detail:
Place of Origin | Shanghai, China |
Brand Name | Sunbright |
Model Number | Sun-603M |
Power Source | DC, AC |
Warranty | 1 YEAR |
After-sale Service | Return and Replacement |
Material | Metal, plastic |
Shelf Life | 1years |
Ceitificate | CE |
Instrument classification | Class II |
Safety standard | Class II |
Type | sign machine |
Display | 12.1 inch color TFT LCD |
Parameter | ECG,RESP,NIBP,SPO2,2TEMP,PR,2IBP,CO2 |
Hours long trend | 480-hour |
ECG waveform | 72-hour |
Multi-languages | Spanish, French, English, Portuguese,Turkish,German and so on |
Application | adult, pediatric and neonatal |
Lead type | 3 lead, 5 lead |
holographic waveform | 40-second |
NIBP measurements | 2400 |
Supply Ability
Supply Ability:20000 Unit/Units per Year vital sign machine
Packaging & Delivery
Packaging Details:Air-worthy packing/Sea-worthy packing for vital sign machine
Port:Shanghai
Features
* Elegant appearance, clear marks, standard interface, OXYCRG SCREEN, trend graph, big characters, other BED observation, which are convenient for user.
* Be applicable for adult, pediatric and neonatal.
* Standard parameters of ECG, RESP, NIBP, SPO2 and dual-channel TEMP. IBP, CO2, Built-in printer, curving handle, moving bracket and hanging bracket are optional.
* Operation interface with Chinese and English. Finish all operations by keys and knobs.(Optional languages: Spanish, French, English, Portuguese, Turkish, German and so on) design with full built-in module, stable and reliable performance.
* 12.1” color TFT LCD with high resolution displays patient parameter and waveform, and alarm, bed NO,clock,state and other information provided by the monitor synchronously.
* Monitoring contents, scan speed, volume and output contents can be set optionally.
* Storage of 480-hour trend data, and review of 40-second holographic waveform.
* Storage and review of 72-hour ECG waveform.
* Function of NIBP review, storage for up to 2400 NIBP data.
* Adopt digital SPO2 technology, which has strong anti-interference and antiweak filling capability.
* Calculation of drug concentration.
* Network: connecting with central station, other Bed observation and software updating. Connection mode: wireless and wired.
* Built-in rechargeable battery for uninterrupted monitoring.
* Print ECG, SpO2, RESP, BP and temperature data with one-key.
* Anti-high frequency surgical unit, defibrillation-proof(requirement for special leads).
* Analysis function for heart rate variability(HRV) (optional).
Introduction
This equipment can monitor such parameters as ECG,RESP,SPO2,NIBP,and Dual- channel TEMP.It integrates parameter measuring module,display and recorder in one device to form a compact and portable device. At the same time, its built-in replaceable battery provides convenience for patient moving.
Performance
ECG | Lead Mode 3-lead and 5-lead are optional Lead Selection I, II, III, AVR, AVL, AVF, V Wave 5-lead: 2 channels 3-lead: 1channel Gain ×2.5mm/mV, ×5.0mm/mV, ×10mm/mV, ×20mm/mV HR Measuring and Alarm Range Range 15 ~ 300 bpm Accuracy ±1% or ±1bpm, which is greater Alarm Accuracy ±2bpm Resolution 1 bpm |
CMRR | Monitor ≥ 100 dB Surgery ≥ 100 dB Diagnosis ≥ 60 dB |
Bandwidth | Surgery 1 ~ 20 Hz(+0.4dB,-3dB) Monitor 0.5 ~ 40 Hz(+0.4dB,-3dB) Diagnosis 0.05~75Hz(+0.4dB,-3dB); 76Hz~150Hz(+0.4dB,-4.5dB) Calibration Signal 1 mV (Vp-p), ±5% Accuracy |
ST Segment Monitoring | Measuring and Alarm Range -0.6 mV~ + 0.8 mV |
ARR | ARR Detecting Type ASYSTOLE, VFIB/VTAC, COUPLET, BIGEMINY, TRIGEMINY, R ON T, VT>2, PVC, TACHY, BRADY, MISSED BEATS, PNP, PNC |
Alarm | Available |
Review | Available |
Scan Speed for ECG Waveform is adjustable | 12.5mm/s accuracy ±10%25mm/s accuracy±10% 50mm/s accuracy±10% |
Respiration | Method R-F(RA-LL) Impedance Differential Input Impedance >2.5 MΩ Measuring Impedance Range 0.3~5.0Ω Baseline Impedance Range 100Ω– 2500Ω Bandwidth 0.3 ~ 2.5 Hz |
Resp. Rate | Measuring and Alarm Range 0~120rpm Resolution 1 rpm Measuring Accuracy ±2 rpm Alarm Accuracy ±3rpm Apnea Alarm 10 ~ 40 S |
NIBP | Method Oscillometry Mode Manual, Auto, continuous Measuring Interval in AUTO Mode 1 /2 /3 /4 /5/ 10/ 15/ 30 /60 /90/120/240/480/960 Min Measuring Period in Continuous Mode 5 Min Measuring and Alarm Range 10~270mmHg Alarm Type SYS, DIA, MEAN |
Resolution | Pressure 1mmHg Cuff Pressure ±3 mmHg Accuracy ±10% or ±8mmHg, which is greater Over-pressure Protection: Adult Mode 315±10 mmHg Pediatric Mode 265±10 mmHg Neonatal Mode 155±10 mmHg |
SPO2 | Measuring Range 0 ~ 100 % Alarm Range 0 ~ 100 % Resolution 1 % Accuracy 70% ~ 100% ±2% 0% ~ 69% unspecified |
Pulse Rate(PR) | Measuring and Alarm Range 0~250bpm Resolution 1bpm Measuring Accuracy ±2bpm or ±2%, which is greater Alarm Accuracy ±2bpm |
TEMP | Channel dual-channel Measuring and Alarm Range 0 ~ 50°C Resolution 0.1°C Accuracy ±0.1°C Actualization Interval about 1 Sec. Average Time Constant < 10 Sec. Alarm responding Time ≤2min |
ETCO2 | Method Sidestream or Mainstream Measuring Range for CO2 0~150mmHg Resolution for CO2: 0.1 mm Hg 0 to 69 mm Hg 0.25 mm Hg 70 to 150 mm Hg Accuracy for CO2: 0 – 40 mm Hg ±2 mm Hg 41 – 70 mm Hg ±5% 71 – 100 mm Hg ±8% 101 – 150 mm Hg ±10% Respiration Rate>80BPM ±12% AwRR Range 2~150 rpm AwRR Accuracy ±1BPM Apnea Alarm Available |
IBP | Channel dual-channel Label ART, PA, CVP, RAP, LAP, ICP, P1, P2 Measuring and Alarm Range -50~350 mm Hg Resolution 1 mm Hg Accuracy ±2% or 1mm Hg, which is greater |
Display Mode 12.1″ color TFT LCD with high-resolution.
Power Supply 220V, 50Hz
Safety Classification class Ⅰ,type CF defibrillation-proof part
Physical Characteristic: Dimension 380×350×300(mm) Net weight 4.8Kg
Accessories
1. Adult SpO2 probe(5-pin)
2. Adult NIBP cuff
3. Extending tube for blood pressure
4. ECG lead
5. ECG electrode
6. Temperature probe
7. Power cord
8. Thermal recording paper(optional)
9. User Manual
